SFP支持SONET、Gigabit Ethernet、光纖通道（Fiber Channel）以及一些其他通信標準。此標準擴展到了SFP+，能支持10.0 Gbit/s傳輸速率，包括8 gigabit光纖通道和10GbE。引入了光纖和銅芯版本的SFP+模塊版本，與模塊的Xenpak、X2或XFP版本相比，SFP+模塊將部分電路留在主板實現，而非模塊內實現。
Electrical Current Rating : 0.5 Ampere Insulation Resistance : 1000 MΩ Min Dielectric Withstanding : 300 V Contact Resistance : 30 mΩ Max | Mechanical Insertion Force : 35N Max Durability : 100 Cycles |
Material Housing : High Temperature Plastic UL 94V-0 Contact : Phosphor Bronze CAGES: Copper Alloy | Plating Contact : Gold plated on contact area Nickel plated overall |
Environment Characteristics Operating temperature : -40℃ to +85℃ |
